特点：
先底封，后对折，再收卷。
自动定长，自动换卷，自动报数。
主要技术参数Main technical specification
|
型号Model |
HSLJ-1000AR |
HSLJ-1200AR |
|
Suitable materials |
HDPE,LLDPE |
HDPE,LLDPE |
|
Max. Unwind diameter |
650mm |
650mm |
|
Max. Bag sealing width |
150-800mm |
150-1000mm |
|
Bag cutting length |
300-1500mm |
300-1500mm |
|
Max. Rewind roll width |
100-350mm |
100-350mm |
|
Max. Rewind diameter |
150mm |
150mm |
|
Machine linear speed |
10-70M/min. |
10-70M/min. |
|
Bag cutting speed |
20-120pcs/min. |
20-120pcs/min. |
|
Main motor |
1.5KW |
1.5KW |
|
Total power |
15KW |
18.5KW |
|
Voltage |
380V, 50HZ, 3 phase |
380V, 50HZ, 3 phase |
|
Film thickness |
0.01-0.15mm |
0.01-0.15mm |
|
Weight |
2400KG |
2800KG |
|
Overall size |
7000x2000x1900mm |
7000x2300x1900mm |
